| Basic technical parameters | |||
| Parameter name | Company | Model and specification | |
| RX01-WL-G1.6 | RX01-WL-G2.5 | ||
| Maximum flow | m3/h | 2.5 | 4 |
| Minimum flow | m3/h | 0.016 | 0.025 |
| Metering grade | Grade | 1.5 | |
| Maximum working pressure | kPa | 30 | |
| Total pressure loss | Pa | ≤250 | |
| Tightness | kPa | Input air 1.5 times the maximum working pressure for three minutes without leakage | |
| Explosion proof standard | / | EXib IIBT3 Gb | |
| Service temperature | ℃ | -10~+40 | |
| Power supply mode | / | Optional lithium battery or alkaline battery | |
| Battery life | / | The service life of lithium battery is more than 10 years, and that of alkaline battery is more than 1 year | |
| Working voltage | V | Lithium battery powered: DC 2.7V ~ 3.8V (optional) | |
| Alkaline battery power supply: DC 4.6V ~ 6.5V (optional) | |||
| Maximum operating current | mA | ≤2000（GPRS） | |
| ≤500（NB-IoT） | |||
| Quiescent current | μA | ≤20 | |
| Sampling mode | Pulse | Reed or hall sampling counting | |
| Direct reading | Photoelectric direct reading | ||
| Valve reliability | / | The number of continuous switches shall not be less than 10000 | |
Long term operation performance | / | It shall meet the requirements of national standard GB / t6968-2019 membrane gas meter after running for 5000h under the maximum flow | |
| Degree of protection | / | IP65 | |
Dimension drawing
| Model / Size | M | S | L | B | H | D | Quality（kg） |
RX01-WL-G1.6 RX01-WL-G2.5 | M30×2 | 130 | 172 | 155 | 225 | 63 | 2 |
