product
RU04 Ultrasonic Gas Meter
RU04 Ultrasonic gas meter is a gas metering terminal. It is a new type of all-electronic metering gas meter that uses the time difference transmitted by ultrasonic in the medium to measure. It is mainly used to measure the gas flow in the pipeline. The realization of ladder gas price, wireless remote transmission, remote valve control, abnormal flow monitoring and other functions, greatly reducing the cost of human resources and network deployment of gas companies.
Technical parameters



Technical Parameters
ItemUnitspecifications
RU04-WL-G1.6RU04-WL-G2.5   RU04-WL-G4
Measuring Rangem3/h
0.016 ~ 2.50.025 ~ 40.04 ~ 6
The interface way/The screw thread，M30
sizemm213.4*156*79.5
The battery/Two ER26500 3.6v
Accuracy/class 1.5
Measurement errorqmin≤q＜qt
±3%
qt≤q≤qmax±1.5%
perature Range℃-10 ~ 40
Explosion Level/
ExibiiBT3 Gb

IP Degree

/
IP67

Dimension drawing

Model/SizeMSLBHDWeight（kg）

RU04-WL-G1.6

RU04-WL-G2.5

RU04-WL-G4

M30×2130203124173.550.51.5


Product size
