Wireless remote transmission diaphraam gas meter
Wireless remote transmission diaphraam gas meter is to collect the actual use data (gas volume, valve, battery) of gas meter by adding intelligent module, read the meter by wireless collector (PDA or Bluetooth collector), and finally upload it to the management system for unified management. The product has strong anti-interference, supports remote valve control and remote price adjustment.
Technical parameters
Basic technical parameters
Parameter nameCompanyModel and specification
RX06-GPRS-G6RX10-GPRS-G10RX16-GPRS-G16RX25-GPRS-G25
Maximum working pressurekPa50
Maximum allowable value of pressure lossPa≤200≤500
Maximum allowable error/               qmin≤q＜qt時，  ±3%
               qt≤q＜qmax時，  ±1.5%
TightnesskPa               Input air 1.5 times the maximum working pressure for three minutes without leakage
Service temperature  ℃-10~+40
Metering gradeGrade1.5
Motor valve lifeFrequency≥10000
Battery type/lithium battery：DC3.6V（1節）
Explosion proof grade/EXib IIBT3 Gb
Degree of protection/IP65

Communication mode

/GFSK/LoRa
FrequencyMHz470-510


Dimension drawing：

型號/尺寸M
SLBHD質量

RX06-GPRS-G6

φ45.8（11牙/吋）/ M42×2/G11/4″

160
249
191
275
77.5
3.3

RX10-GPRS-G10

G2″/φ56.8（11牙/吋）/ M64×2

180
284
216.8
335
92
5.3
RX16-GPRS-G16

G2″/φ56.8（11牙/吋）/ M64×2

220
333
243
374
105.5
7.8
RX25-GPRS-G25

G2 1/2″/M80×3/φ76.2（11牙/吋）

280
411.5
289
437.5
129.5
13.2



Product size
